Long Endurance Fuel Power Fixed Wing gasoline VTOL UAV Surveillance Survey Mapping Gasoline Engine KIT Frame
- Options
-
- Aluminum Box
- KIT composite material
Description ：
Long Endurance Fuel Power Fixed Wing gasoline VTOL UAV Surveillance Survey Mapping Gasoline Engine KIT Frame
FLY-330 gasoline VTOL is a professional and high-performing VTOL HYBRID UAV offering outstanding efficiency and elegance. The system has been designed to flexibly, quickly and safely integrate different sensors in order to meet the needs of a variety of fields of application. The high quality standards combined with the extremely simple operating concept and high aerodynamic quality makes the system unique in its comparative class. The FLY-330 can autonomously and safely take off and land vertically with highly sensitive sensors on a minimum area. With no need for any take-off or landing runways.
| Model features | |
| Vertical take-off and landing | Low requirements for landing and landing points, high operating efficiency. |
| Simple structure | Easy to operate in a short time. |
| Full autonomous flight | One-button take-off, safe and efficient. |
| High security | Double protection for emergency landing and open umbrella. |
| Flight duration | 5-8 Hours with 8L gasoline loading |
| Aircraft Parameters | |
| Cruise speed | 100-120Km/H |
| Aircraft length | 2100MM |
| Wing width | 3300MM |
| Maximum takeoff weight | 40KG |
| Flight altitude | Maximum 4500m |
| Payload | Maximum 10KG |
| Wind resistance | Grade 6 |
| Power System | 60cc-100cc Gasoline Engine-Electric |
| Body material | Full composite material |
Autopilot performance:
full coverage of the model;
Satellite navigation
[real-time GPS/GLONASS/Galileo/B Multi-system signal reception];
attitude accuracy 0.5°, heading accuracy 1°;
centimeter-level positioning;
High precision and high dynamic motion measurement.
NOTE： THE PRICE IS JUST KIT, WITHOUT ANY ELECTRONIC, AND THE PACKING IS IN WOODEN CASE, IF YOU NEED ALUMINUM BOX, NEED TO ADD COST INDEPENDENT !
